8+4Gbit port managed industrial PoE switch
News

8 and 4Gbit port managed industrial PoE switch

The IPS7112G-4GS-8POE from 3onedata is an industrial grade, managed and redundancy Ethernet switch which supports 8 Gigabit PoE ports and 4 Gigabit SFP slots. The switches are classified as power source equipment (PSE) which can be used to power IEEE802.3af/at standard devices (PD), eliminating the need for additional wiring.

The IPS7112G-4GS-8POE provides some kinds of advanced network managed function, such as: SW-Ring redundancy ring network, STP/RSTP/MSTP, VLAN, Trunking, 802.1X, SNMP, LLDP, SSH, Quality of Service, Speed control, port mirroring, fault alarm and firmware upgrade online.



The IPS7112G-4GS-8POE accorded to CE, FCC standard and industry grade 4 design requirements, supports 2 channel DC power input and 1 channel relay alarm output, an -40 to70°C operating temperature and a wide 48VDC voltage power supply input.

Features

  • 8 Gigabit Ethernet copper ports and 4 Gigabit SFP ports
  • PoE power supply intelligent management
  • Compatible with both IEEE802.3at (30W) and IEEE802.3af (15.4W)
  • Port based VLAN and IEEE 802.1Q VLAN
  • SW-ring ring network patent technology (fault recovery rime <20ms)
  • Support WEB, SNMP and Telnet configuration
  • 2 channels power input support
  • 1 channel relay alarm output
  • Industrial grade design
  • Operating temperature: 40 to 75°C
  • Support redundancy DC power supply 48VDC
  • IP40 protection grade
  • DIN-Rail mounting

Applications

  • IP surveillance cameras
  • Process automation
  • Transportation
  • VoIP data
  • Wireless access points
